Ayrton MagicPanel-R
Description
Ships from outside of the United States
These Ayrton MagicPanel-R LED moving lights have heavy wear and tear, but are in good working condition. Power cables and other accessories are not included.
The Ayrton MagicPanel-R is an IP20 continuous-rotation moving head wash light built around high-output, multi-chip RGBW LEDs. Designed for dynamic stage and event lighting, it delivers tight, punchy beams and pixel-mapped effects while also producing smooth, even wash coverage when needed.
RGBW Color Mixing and Pixel Control
This luminaire uses the CMY additive color principle with red, green, blue, and white sources to create saturated colors, pastels, and clean white presets. It features 25 independently controllable 15 W LEDs, enabling pixel-level chases, blocks, and graphic looks across the array. The virtual color wheel includes white light presets, fixed colors, and reprogrammed dynamic color changes.
Output, Beam, and On-Camera Performance
With up to 11,500 lumens and a 4.5° beam angle, the MagicPanel-R is suited to cutting through ambient light for aerial looks and defined beam work. A guaranteed “no-flicker” effect makes it a practical choice for television applications and video-recorded events.
Control and Effects
Remote control is via DMX512 with a flexible footprint of 18 to 116 DMX channels, and it is compatible with the DMX/RDM (Remote Device Management) protocol for streamlined addressing and status monitoring. It includes an electronic dimmer (0 to 100% without color change, 16-bit), high-speed strobe (1 to 25 flashes/second), pre-programmed variable strobe effects, and macro modes. Onboard menus support DMX addressing and advanced functions, with an information menu for timer, temperature, and software version.
Power and Physical Specs
- Optical efficiency: 85% maximum
- Estimated LED emitter lifespan: 50,000 hours
- Electronic power distribution with PFC: 110-240 VAC, 50/60 Hz
- 430 W maximum power
- Power supply via powerCON TRUE1 connector
- Dimensions (WxHxD): 433 mm x 578 mm x 307 mm (17.05" x 22.8" x 12.09")
- Weight: 19.9 kg (43.9 lbs)
Additional Details
| Ships From: | United Kingdom |
| Manufacturer: | Ayrton |
| Condition: | Good |
| Item #: | 62308 | Brokered |
| Tags: | Moving lights, Leds, Uk items, Ayrton, Led moving lights |
- Optical efficiency: 85% maximum
- Opening angle of the beam: 4.5°
- 25 high-power multicolor LED emitters
- Brightness: up to 11,500 lumen
- Estimated lifespan of LED emitters: 50,000 hours
- Guaranteed “no-flicker” effect perfectly suited for television applications and all video recorded events
- System of 4-color mixing (red, green, blue and white) ensuring a high color-rendering index (CRI)
- Uniformly produced light, without shadows, and offering rich saturated shades and pastel hues in 4.29 billion colors (8-bit resolution).
- Virtual color wheel including white light presets Fixed colors and reprogrammed dynamic color change
- Electronic dimmer for light adjustment from 0 to 100% without color change (16-bit)
- High-speed strobe effect in white or color at 1 to 25 flashes/second
- Pre-programmed variable strobe effect
- Full menus for setting DMX address and advanced functions
- Compatible with the DMX/RDM (Remote Device Management) protocol
- Pre-programmed macro modes
- Information menu including: timer, temperature, software version, etc.
- Electronic power distribution with Power factor Correction (PFC) from 110-240 VAC, 50/60 Hz
- 430 W maximum power
- Power supply via powerCON TRUE1 connector
- Dimensions (WxHxD): 433 mm x 578 mm x 307 mm (17.05" x 22.8" x 12.09")
- Weight: 19.9 kg (43.9 lbs)
- (1) MagicPanel-R
- Power cables and other accessories are not included.
