Production Bot Switch 8 w/ Control Surface
Description
Production Bot Switch 8 w/ Control Surface
The Production Bot Switch 8 w/ Control Surface is a dedicated live production and streaming system built around vMix workflows, combining a high-performance Windows 11 PC with hands-on switching control. Designed for multi-camera events, houses of worship, corporate streams, and mobile production, it supports up to 8 simultaneous live HD-SDI video sources with embedded audio, plus extensive media, graphics, and remote-guest inputs for complete show builds in a single platform.
Live switching, mixing, and show graphics in vMix
This system includes vMix Pro, vMix Social, and vMix Title Designer for building polished broadcasts with professional transitions and layered compositions. Each input includes 5 “Multi View” overlay channels (Mix/Effects) to combine elements like logo bugs, lower thirds, titles, and text. For finishing layers, it provides 4 downstream keyers (DSKs) with individual transitions, alpha channel support, and adjustable scaling/positioning.
For visual refinement during production, it supports real-time color correction and image processing including Deinterlace, Sharpen, Zoom, Rotate, Pan, and Crop, with effects processed in 4:4:4 32bit color space for video fidelity.
Video and audio I/O for multi-camera workflows
Video inputs support any combination of HD and SD formats, with embedded SDI audio available as 16-channel SDI embedded audio, plus compatibility with USB audio devices. Outputs include 2x 3G/HD/SD-SDI plus display connections for monitoring and multiviewer setups (2x DisplayPort 1.4, 2x HDMI 2.0, 2x DVI-D Dual-link). Audio outputs include 1/8” stereo and 2-channel SDI embedded.
For monitoring and control, the built-in audio mixer provides independent control and monitoring of audio sources with Mute, Solo, Follow (Auto Mixing), Delay, EQ, Compressor, and Gain. Multiview is supported via secondary display or HD-SDI with configurable layouts, titles, audio meters, and tally display.
Recording, streaming, replay, and remote contributions
The Switch 8 is built for simultaneous record, stream, and output to multiple formats and resolutions. Recording formats include AVI, MP4, MPEG-2, MOV, and MXF for both Program and ISO recordings, with multiple compression options. For live streaming, it supports RTMP streaming to CDNs including Twitch, LinkedIn, and YouTube.
To support modern productions, it includes NDI for multi-channel video input and output over Gigabit Ethernet using the open Network Device Interface protocol. It also includes vMix Call for bringing up to 8 remote guests into productions using only a web browser and webcam, plus integrated social media tools for live or queued insertion of Facebook, Twitter, or IRC feeds with content approval from any web-connected device. Instant Replay is built in for continuous multi-camera recording and playback.
Performance, storage, and system specifications
- CPU: 7-11700K 5.10 Ghz processor
- GPU: RTX A5000 24GB DDR6 graphics
- Memory: 32GB Memory
- Networking: Gigabit LAN
- OS: Windows 11 Home
- Storage: 500GB Internal SSD Storage, 1TB additional storage in removable hot-swap bay, 4 Hot-swap SSD Drive bays for potentially unlimited plug and play storage
Supported formats and physical details
Supported live video formats include 1080P, 1080i, 720p, and SD, with multi-format capability. Supported frame rates include 23.98, 24, 25, 29.97, 30, 50, 59.94, and 60. Dimensions are 7" (D) x 13.5" (H) x 16.9" (W).
Additional Details
- 7-11700K 5.10 Ghz processor, RTX A5000 24GB DDR6 graphics, 32GB Memory, Gigabit LAN, Windows 11 Home, vMix Pro, vMix Social and vMix Title Designer
- Storage: 500GB Internal SSD Storage, 1TB additional storage in removable hot-swap bay, 4 Hot-swap SSD Drive bays for potentially unlimited plug and play storage.
- Video Inputs: Up to 8 simultaneous live HD-SDI video sources w/embedded audio in any combination of HD and SD format
- Audio Inputs: 16-channel SDI embedded, compatible with USB devices
- Media: Up to 1000 multi-source inputs including video/audio files up to 4K resolution, PowerPoint (Microsoft Office Req.), graphics, streams, desktop apps, titles, live social media.
- Transitions: Cut, Fade, Zoom, Wipe, Slide, Fly, CrossZoom, FlyRotate, Cube, CubeZoom,VerticalWipe, VirtualSlide, Merge and two custom Stinger channels.
- Mix/Effects: Each input includes 5 “Multi View” overlay channels to create complex Mix/Effects. Add logo bugs, lower thirds, titles, text in combinations to create compelling productions.
- Downstream Keyers: 4 DSKs / overlays with individual transitions, alpha channel and custom scaling/positioning.
- Image Adjustment: Color Correct, Deinterlace, Sharpen, Zoom, Rotate, Pan and Crop any input in real time. All effects are processed in 4:4:4 32bit color space for optimal video quality.
- Audio Mixer: Independent control and monitoring of all audio sources with Mute, Solo, Follow (Auto Mixing), Delay, EQ, Compressor and Gain.
- Desktop capture: Included screen capture from local/remote PC-Mac sources
- vMix Call: Live interview solution for up to 8 guests. connect guests into your live show with HD video and high quality video with only a web browser and a webcam
- NDI: Support for multi-channel video input and output over a Gigabit Ethernet network using open Network Device Interface protocol
- Instant Replay: Multi camera instant replay system built in with continuous recording and playback.
- Social Media: Integrated application for live or queued insertion of Facebook, Twitter or IRC feeds. Approve and control content from any web-connected device
- Output: Simultaneous record, stream and output to multiple formats/resolutions
- Video Outputs: 2x 3G/HD/SD-SDI, 2x DisplayPort 1.4, 2x HDMI 2.0, 2x DVI-D Dual-link
- Audio Outputs: 1/8” Stereo, 2-channel SDI embedded
- Recording: AVI, MP4, MPEG-2, MOV and MXF for both Program and ISO recordings with a variety of compression formats available.
- Live Streaming: RTMP streaming to any CDN including Twitch, LinkedIn,YouTube and more
- Multiview: Live multiviewer output to secondary display or HD-SDI with configurable layouts and titles, audio meters and tally display.
- Supported Live Video Formats: 1080P, 1080i, 720p and SD Multi Format capable. 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 frame rates supported.
- Dimensions: 7" (D) x 13.5" (H) x 16.9" (W)
- (1) Switch 8
- (1) Control Surface
