Martin MAC Quantum Profile

The Martin MAC Quantum Profile is an extremely bright LED moving head profile fixture designed for crisp gobo projection on surfaces as well as mid-air, making it a strong fit for concerts, touring rigs, theaters, and installed venues that need fast looks and reliable, consistent output from LED technology.

Ships from outside of the United States

These Martin MAC Quantum Profile LED moving lights have heavy wear but are in good working condition.

This fixture combines a flat field with a crisp, high-contrast image, plus a fast, smooth CMY color mixing system for accurate color fades and quick palette changes. A 1:3 motorized zoom and motorized focus with zoom-focus tracking help keep projection sharp across a range of throw distances.

For beam and aerial effects, it includes an Animotion FX system for beam animations, a rotating three-facet prism, and an electronic shutter with variable-speed regular and random strobe. Creative shaping tools include an iris (0 to 100%) with pulse effects, plus both rotating and static gobo wheels for layered textures and motion.

Color, Gobos, and Effects for Show Programming

• CMY color mixing, independently variable 0 to 100%
• Color wheel with 6 color filters plus open
• Rotating gobo wheel with 6 interchangeable gobos plus open, wheel rotation, gobo rotation, indexing, and shake
• Static gobo wheel with 10 gobos plus open, wheel indexing, rotation, and shake
• Rotating three-facet prism
• Electronic shutter with variable-speed strobe (regular and random)

Movement, Control, and Performance Details

• Pan 540 degrees, tilt 268 degrees
• Adjustable pan and tilt speed via onboard control panel and DMX
• Electronic dimming with four dimming curve options
• Motorized zoom and motorized focus (with zoom-focus tracking)
• Consistent photometric performance via LED technology

Size and Weight

• Length: 452 mm (17.8 in.)
• Width: 431 mm (17.0 in.) across yoke
• Height: 642 mm (25.3 in.) head straight up, 648 mm (25.5 in.) maximum
• Weight: 23.2 kg (51.1 lbs.)

With a very low weight and compact design, plus super high-speed movements and effects, the MAC Quantum Profile is described as the first real 700/800 W discharge lamp replacement in a profile fixture that effectively harnesses cutting-edge LED technology.
